Recintha Safety

– 80×60 mm rectangular post, thickness 3 mm

– 120×60 mm rectangular post, thickness 2 mm

– Hot-dip galvanized and polyester powder coated finish

– Available models: for concrete anchoring

– With either threaded inserts to suit mesh clips, or with cover plate and security bolt

– 120x60x30x3 mm OMEGA post with 120×4 mm cover plate

– Predrilled for security bolt installation

– Hot-dip galvanized and polyester powder coated finish

– Available model: for concrete anchoring

– 60x40x25 mm OMEGA post with 90×4 mm cover plate

– Predrilled for security bolt installation

– Hot-dip galvanized and polyester powder coated finish

– Available model: for concrete anchoring

– Posts with different profiles can also be provided for specific requirements.

– For all fences (excluding DEFENDER).

– Predrilled fixing clip

– Easy to install, it guarantees a high level of security

– Available both in hot-dip galvanized and polyester powder coated finish

– Fencing accessory to install barbed wire

– Provided with 3 holes to fix barbed wire

– Single or double version available on request

– Material: hot-dip galvanized finish

– Polyester powder coated finish on demand

– Suitable for posts: 60×60 mm square tube, 60×40 mm and 120×60 mm OMEGA sections

M6x35 TTQST SS

SCREW M6 SS BOLT

M8x35 TTQST SS

SCREW M8 SS SECURITY BOLT

M8x80 TTQST SS

SCREW M8 SS SECURITY BOLT

– The cap fully seals off the post, preventing water infiltration

– Material: Moplen

– OMEGA post cap in pre-galvanized and painted steel

– Recintha Safety U-section profile optional accessories

– Makes Recintha Safety installation easier and improves its straightness

– Can be installed either at panel top or bottom and at both

– Screwed to the mesh

– Material: hot-dip galvanized and polyester powder coated

– 32x16x32x2 mm U-shaped profile predrilled to fix it to the panel

The most advanced electronics integrated in the solidity of Defim Orsogril fences. MACS (MEMS-based anti-climbing system) accurately detects attempts to break in and pass over, discriminating between natural or accidental events with great precision. Easy to install and remotely monitored, it is an important step forward for perimeter security. Adaptable to any project, thanks to a self-learning technology, adapts to the fence on which it is installed and can be updated over time.

Macs Fences integrated

MACS is specially designed to integrate harmoniously and functionally with the Recintha Safety model. A new and higher safety system is thus defined to guarantee an elegant design perfectly integrated, respecting the Italian style, invisible with inaccessible sensors and cables, designed for Defim Orsogril fences.

Macs Fences External

MACS’ advanced electronics has been developed to extend all the benefits of intelligent protection to a wide range of Defim Orsogril fences. Thanks to the compact design of the sensor, MACS integrates in a distinctive and elegant way with the different solutions. You can choose different colors of the cable to match the project in which the system is inserted. With the central single screw mechanism, installation is quick and easy. MACS is compatible with: Recintha N/L, 202, Sterope, Pleione, Britosterope and the Talia line.

Remote control also for your fences

The MACS system can be remotely managed with an integrated portal thanks to the presence of a network card with Ethernet communication for programming and reprogramming the different zones of the fenced perimeter, also with different sensor settings and monitor events in real time.

All this is possible in a smart way, thanks to an interface with a web browser accessible also on mobile devices and it is designed with different levels of interaction to allow its use both to the professional and to the end user.

M8x40 TTQST SS

SCREW M8 SS SECURITY BOLT
