Potissimum Industria
POTISSIMUM® INDUSTRY is the electrowelded steel grating that, thanks to an advanced production process, is exceptionally strong but also highly versatile and suitable for use in disparate industrial sectors.
Projects ranging from the simplest to the most complex can be customised with bespoke framed and shaped panels. The Design Department, a benchmark in the sector, assists the customer in the design phase to identify the most suitable and economic solution for his needs. Both the stocked Standard GEAs in 6100×1000 mm format and the cut-to-size material are CE marked and supplied with the relevant Protected Designation of Origin (PDO).
Material
UNI EN 10025 S 235 JR steel
Coating
EN ISO 1461 hot-dip galvanisation
Painting
Colours according to RAL table
Accessories
Grating hook fasteners
Floors
Stairs
Water traps
Industrial flooring
Mezzanine floors
Orsogril POTISSIMUM® industrial electrowelded grating – Bespoke framed electrowelded grating panels (bearing bar – mesh)
Mesh size mm: 30/34 x …
Bearing bar mm: …
Twisted square crossbar mm: …
Banding flat bar …. mm with continuous groove, electrowelded to the panel (for regular panels)
Weight kg/m²: …
Material: UNI EN 10025 S235JR steel
Finish: EN ISO 1461 hot-dip galvanisation
AGLAIA grating hook fastener for mesh size …. mm – bottom or top fixing
CE certificate (Ref. Factory Production Control Certificate 0948-CPR-0287)
